The Caddy doesn’t give you acres of room, so the shelving needs to earn its place.

Pack-A-Shelf works well in the Volkswagen Caddy because it gets Packout boxes and tools up off the floor without filling the whole cargo area with a fixed fitout. You can keep the setup fairly simple in a standard Caddy, or build more storage into a Caddy Maxi where there’s extra length to play with.

VW Caddy Shelving Fit Guide

The current Caddy Cargo has 1,797mm of load-floor length, while the Caddy Cargo Maxi has 2,150mm. Both are listed at 1,614mm wide in the load compartment. That gives both vans enough raw length for the 1,000mm Mini Slider and 1,350mm Dual Slider, but the final fit still depends on wheel arches, lining and where the unit is mounted.

Fitting Out a VW Caddy

Make the wall space do some work

The Caddy is a compact van.

Once a couple of Packout boxes, a vacuum, stock and a few awkward tools hit the floor, that space disappears pretty quickly.

Shelving gets the boxes up where you can see them.

The Full Width Shelf carries one full-width or two half-width Milwaukee Packout boxes. The Half Width Shelf works where you don’t want to give up a full section of wall.

That’s handy in a Caddy because you can work around the gear rather than building one big rack and hoping everything fits around it.

Keep the floor for the heavy stuff

Not everything needs to go on a shelf.

Heavy tools, machines and anything awkward are usually better kept down low.

Use the walls for the boxes and smaller gear. Keep some floor space open for the stuff that changes from job to job.

A Caddy packed completely full of shelving might look organised, but it doesn’t leave much room for anything unexpected.

Caddy Cargo vs Caddy Maxi

The main difference for a shelving setup is length.

The standard Caddy Cargo gives you 1,797mm along the load floor.

The Maxi stretches that to 2,150mm.

The width is the same at 1,614mm, so you’re not really getting a wider van with the Maxi. You’re getting more length to spread the setup out.

That extra room can be useful if you want shelving plus a slider, longer tools or some open cargo space behind the system.

Keep the Packout boxes where you can reach them

One of the easiest ways to make a small van annoying is to stack cases on the floor.

The one you need ends up underneath the other two.

Pack-A-Shelf is built around Milwaukee Packout boxes, so the cases have somewhere to sit without being buried.

The modular wall sections also have mounting holes every 15mm. If your box setup changes later, the shelf height can change with it.

Will the Sliders Fit a Caddy?

On the published cargo length, yes.

The Mini Slider body is 1,000mm long.

The Dual Slider is 1,350mm.

Both are shorter than the 1,797mm load-floor length of the standard Caddy Cargo, and there’s more room again in the 2,150mm Maxi.

That doesn’t mean bolt it in without measuring.

The sliders also need 420mm of clear width, room around the triggers and enough space outside the van for the unit to extend.

The Mini Slider extends to 2,000mm.

The Dual Slider extends to 2,700mm.

Check the side door or rear door you plan to use before deciding which way the slider should run.

What to Measure Before Ordering

Don’t just work from the Caddy dimensions above.

Once ply lining, wheel arches and other gear are in the van, your usable space can be different.

Check:

• Clear wall width

• Available height

• Clear floor length

• Wheel-arch position

• Side-door opening

• Rear-door opening

• Internal ribs

• Ply lining

• Wiring

• Anything already installed

Volkswagen lists the current Caddy Cargo side-door opening at roughly 695–703mm wide depending on configuration, while the Maxi gets the wider 836–846mm opening. Both use a 1,234mm-wide rear opening.

Measure your actual van anyway.

That’s the measurement that matters.

Can It Be Fitted Without a Full Custom Fitout?

Yes.

That’s one of the reasons Pack-A-Shelf suits a Caddy.

You don’t need to turn the whole back of the van into a permanently built workshop just to organise your Packout boxes.

The shelves and modular walls can be built around the space you’re using.

Whether drilling is needed depends on the mounting points and lining in your particular van. Some vans give you usable factory points. Others need proper fixings added.

Check what’s behind the panel before drilling anything.

Caddy Van Shelving FAQs

What is the best shelving for a VW Caddy?

For most Caddy work vans, modular shelving makes sense because the cargo area is compact and the gear tends to change.

Pack-A-Shelf uses the vertical wall space for Milwaukee Packout boxes without taking over the whole floor.

Does Pack-A-Shelf fit the VW Caddy and Caddy Maxi?

Yes, the Pack-A-Shelf component sizes sit within the published load dimensions of both the current Caddy Cargo and Caddy Cargo Maxi.

The exact layout still needs to be checked against your van’s lining, wheel arches, mounting points and anything already installed.

Can I install Caddy shelving without drilling?

Sometimes.

It depends on the factory mounting points and what lining is already fitted. Where drilling is needed, check behind the panel first for wiring and structural sections.

How much does VW Caddy shelving cost?

It depends on how much of the van you want to fit out.

A basic shelf setup will cost less than a larger build using multiple walls, shelves and sliders. Check the current Pack-A-Shelf pricing or send us your van details and we can help work out what you actually need.

Will shelving reduce the Caddy's payload?

Yes.

Anything fitted to the van counts towards its loaded weight. Volkswagen lists current Caddy Cargo payloads in roughly the 731–778kg range depending on variant and engine, but the final available payload changes with vehicle specification and other equipment already fitted.

Keep the shelving weight in mind along with tools, stock and everything else travelling in the van.

Get the Caddy Set Up Properly

A small van doesn’t need a complicated fitout.

Get the cases off the floor. Keep the everyday tools where you can reach them. Leave a bit of room for the gear that doesn’t fit neatly anywhere.

Shop Pack-A-Shelf van shelving

You can also see our other van setups for Toyota HiAce and Ford Transit.

Not sure what fits your Caddy? Send us the model, a few photos and inside measurements and book a custom design consultation.
